| Name: | XN-7006VT |
| Feature List: |
(1) GSM Quad-band (2) GPS+GSM+GPRS wireless network (3) High sensitive GPS chipset (4) Real-time tracking (5) Built-in GSM&GPS antenna (6) Built-in ON/OFF power, wide voltage input range (7) Built-in acceleration sensor for vibration alarm (8) Support ACC detection, real-time reporting car status (9) Built-in 450mAh battery for alarm when the power supply is disconnected unexpectedly (10) Tele-cut off (petrol/electricity) function (11) SOS button for SOS alarm (12) Voice monitor function (13) Built-in CPU, eliminating breakdown automatically (14) Three LED indicators: GPS-blue; GSM-green; Power-red (15) Check location via platform |
| GSM: | 850/900/1800/1900MHz |
| GPRS: | Class 12,TCP/IP built-in GSM Module |
| GPS: | Mt3326 |
| GSM Antenna: | Built-in quad band |
| GPS Antenna: | Built-in GPRS high gain ceramics patch antenna |
| GPS Channels: | 20 |
| Tracking Sensitivity: | - 159dBm |
| Acquisition Sensitivity: | - 144dBm |
| Locating Time Cost: | Hot start < 2 sec ( open Sky ) |
| Warm Start: | < 15 sec |
| Cold Start: | < 38 sec ( open Sky ) |
| Application Environment: | Operating temperature:-25 °C to + 60 °C Operating humidity: 5% to 95% RH |
| Battery: | 3.7vDC/450mAH |
| Monitoring Rang: | 5M |
| Working Voltage/Current: | 9-36vDC/90mA |
| LED Indicator: | Three LED indicators: GPS-blue; GSM-green; Power-red |
| Dimensions: | 105.8(L) * 54.5(W)*16.4(H) mm |
| Weight: | 96g |
| Certifications: | E-mark, CE |
 |
|
| Name: | XN-7200VT |
| Frequency: | 850/900/1800/1900MHz |
| GPRS: | Class 12, TCP/IP |
| Memory: | 64 MB |
| Phase Error: | RMS phase error < 5, Peak phase error < 20 |
| Max. RF Output Power: | GSM850/GSM900:33±3db |
| GSM Chipset: | MT3326 |
| Frequency: | L1,1575.42MHz C/A code |
| GPS Channel: | 66 channels |
| Positioning Accuracy: | < 10 meters |
